Model	Volume	Demision	Weight	In/Out	DOL.Init.	Compressor	Consumption
BD002	0.3	140¡Á793	15	15	5	5.5	8.7
BD007	1	217¡Á995	30	15	15	7.5	26.8
BD015	2	319¡Á1184	60	25	60	15	54
BD020	3.3	406¡Á1521	135	50	95	18.5	87.7
BD030	6	508¡Á1523	155	50	155	22	155.2
BD050	8.3	610¡Á1550	210	50	220	45	222
BD100	15	764¡Á1578	250	80F	300	90	398.2
BD150	21.6	930¡Á1673	320	80F	480	132	575.6
BD200	30	1088¡Á2332	520	100F	765	160	788
BD200(T)	30	770¡Á2241¡Á1890	735	100F	600	160	796.4
BD300	41.6	1262¡Á2383	975	100F	990	250	1104.2
BD300(T)	41.6	935¡Á2750¡Á2526	875	100F	960	250	1151.2
£ªbased on Inlet temperture 38¡æ, and pressure7kg/cm2.  £ªDesiccant  consumption is based on an operating time of 6000 hours per year.   £ª Designed to withstand pressure of 9.9kg/cm2, more than 10kg/cm2 must be made to order.  £ªT=Twin tower        Download
